Heavy-Duty Welded, ZT-100, 19-W-4 Spacing, Carbon Steel Galvanized Steel Grating 1" x 1/4" Rectangular Bar

Steel gratings are widely used in platforms, walkways, trestle bridges, trench covers, manhole covers, etc. in the fields of petrochemical, electric power, tap water, sewage treatment, port terminals, building decoration, shipbuilding, self-propelled parking lots, municipal engineering, environmental sanitation engineering, etc.

19-W-4 welded, heavy-duty carbon steel bar grating is available in widths up to 3’ and lengths up to 24’. Available in bar thicknesses of 1" x 1/4, 1" x 5/16" and 1" x 3/8".

Heavy-duty grating is used in applications where stronger gratings are required. This type grating will span greater distances and, when engineered correctly, is used extensively for rolling loads such as trucks or forklifts.

Heavy-duty carbon steel grating is manufactured by a resistance-weld process. Cross bars are fused to bearing bars to form a permanent joint. Bearing bars are spaced at 1-3/16” on center and cross bars are 4” on center. Available in smooth, serrated, and non-slip surfaces.

Finished available include mill, black primer, and hot dipped galvanized.

Reference:

The information provided below is your guide for choosing the right Bar Grating product for your project. Ordering information for

1---Application
You need to Consider Bar Grating uses and physical requirements for your interior or exterior application. Loading, span and support needs as well as traffic requirements such as pedestrian, hand cart and vehicular are important considerations.

2---Product Spacing
Select the product spacing (the measurement from the center of one bearing bar to the center of an adjacent bearing bar) of the Bar Grating item. For example, the first number refers to the bearing bar spacing measured on center (19 = 19/16" or 1-3/16"), the letter refers to the construction type (W = welded), and the last number references the cross bar spacing measured on center (4 = 4").

3---Product Sureface Treatment
Select the primary material type including Aluminum, Carbon Steel, Galvanized Steel or Stainless Steel. Inventory is typically "mill finish" for Aluminum, Carbon Steel and Stainless Steel. Hot-Dipped Galvanized, Black Paint finishes are available for some Carbon Steel items.

Products Pictures

Zhuote Metal Grating is manufactured from a swaging process that involves pre-punched load-bearing bars being swaged together with square crossroads. Various load-bearing bar depths and thicknesses are available through the aluminium range and this material is best suited in corrosive applications such as near the ocean or in water treatment plants.

If you have a requirement outside of standard profile, contact our team today to discuss what we can offer you.

  Hebei Zhuote wire mesh products Co., LTD

We are Hebei Zhuote wire mesh Products Co., LTD., our company is located in the intersection of Beijing, Tianjin, Shijiazhuang three cities - the famous "China wire mesh town"

Peace. The company covers an area of 30000㎡, has more than 100 employees.

 As a modern enterprise, specializing in the production of steel grid plate,Grid plate, step plate, platform plate, punching plate series, guardrail net and other products.

The company is equipped with four automatic large-scale pressure welding production lines, welding technology is exquisite, beautiful, solid, smooth and burr free. In recent years, the company's sales increased steadily, last year's domestic trade sales of 75 million dollars, export sales reached 45 million dollars, domestic product sales involved in chemical energy, power plant substation, sewage treatment plant, new energy engineering, logistics transfer station, municipal engineering, for the domestic construction of a force. At the same time, the products are exported to Southeast Asia, Europe, the Middle East, Africa and other regions, and also create considerable foreign exchange income for the local.
