Compact Steel Driveway Drainage Cover Q316 Stainless Steel Grating
HEEL GUARD technology drain grates are constructed with your safety
in mind. We’ve created our stainless steel drains in a grid form
with a non-slip finish that is easy to walk across. The holes are
also small enough that any worries about your child’s fingers being
stuck in there, or something falling in, are unfounded. The grid
form is also aesthetically pleasing, with a narrow profile
specifically designed to blend into all types of flooring.
Our stainless steel grates are perfectly suited to public spaces,
such as public plazas, railway stations, outdoor malls or
streetscapes. They are slip resistant and can be walked across
safely, even while wearing high heels, as they will not get caught.
This unique design prevents possible falls and injuries, reducing
the risk of lawsuits. Also, all our HEELGUARD gratings are designed
to withstand high volumes of foot traffic and withstand the test of
time.
Heel guard grates are constructed by keeping in mind the safety of
the people, so companies manufactured that type of grate on which
people walk quickly and do not slip while crossing it. The holes in
the heel guard grate are also tiny, so people don’t need to worry
about their heel stuck in it, their children’s fingers stuck there,
or anything falling on it will not be found. Grates have a narrow
profile that is designed in this way that they will blend into any
flooring. The heel guard stainless grates are ideally suited for
public places like railway stations, streetscapes, public plazas,
and outdoor malls. Its unique design reduces the risk of lawsuits,
prevents the possibility of falls and injuries. You can use heel
guard grates to handle high foot traffic without worrying about any
maintenance issues and reduction in safety measures.
Parameters | Data |
Bear Bar Type | Flat Bar, I-Bar, Serrated Bar, etc.. |
Bearing Bar Size | 20x5mm, 25x3mm, 35x5mm, 40x5mm, 50x5mm, 60x5mm, etc.. |
Bearing Bar Spacing | 20mm, 25mm, 30mm, 33mm, 40mm, 43mm or multiplier. |
Cross Bar Type | Twisted Steel Rod, Flat Bar |
Cross Bar Size | 3mm, 4mm, 5mm ,6mm or thicker |
Cross Bar Spacing | 50mm or 100mm |
Bearing Bar Length | Customerized from 1000mm to 6000mm or more |
Cross Bar Length | Under 1200mm |
Material Grade | Mild Steel(Q235B), Stainless Steel 304 or 316, etc. |
Treatment Available | Hot dipped Galvanized, Anodized, Polished and Powder Coated |
Standards | Steel Grating Standard | Steel Material Standard | HDG Coating Standard |
China | YB/T4001-1998 | GB700-88 | GB/T13912-92 |
USA | ANSI/NAAMM(MBG531-88) | ASTM-A36 | ASTM-A123 |
UK | BS4592-1987 | BS4360(43A) | BS729 |
Australia | ASl 657-1992 | AS3679 | ASl650 |
Product display:
Application:
indoor:bathroom, shower room, kitchen, Shopping mall, Super market,
warehouse, Hotels, Clubhouses, Gyms, Spas, Restaurants, etc.
outdoor:walkway,square, New Construction, Resorts, Driveways,
Balconies,Pools, Storm Drainage,Universities, Schools, Office
Buildings, etc
Product certification
FAQ
1. How can I get a catalogue?
Please call us or send us email. We will reply within 24 hours.
2. Is customized product available ?
Besides common size, we accept customized fabrication. Just let us
know your requirements.
3. How long after I place an order can I expect delivery?
This depends on the product chosen. We will always try to fit in
deliveries to meet customer requirements, so if you have a specific
deadline please talk to us. Some of our products are custom made,
so will have a longer delivery time, but we can give you an
estimated delivery date at the time of placing your order. We aim
to complete the majority of deliveries within 15 days.
