Heavy-duty customizable anti-corrosion non-slip breathable steel
grating galvanized
Steel Grating Specification Available:
Bearing bar:25mmx3mm,30mmx2mm,30mmx5mm,35mmx5mm
Cross rod:6mm-8mm twisted rod
Bearing bar pitch:30-40mm
Cross rod spacing:100mm
Panel size:100*100cm, 100*300cm,914mm width*5.8m long.
Surface:hot dip galvanized/ stainless steel/painting.
Material:Q235 iron steel.
1. Material :Mild steel & Low carbon steel, etc.
2. Surface process: hot-dipped galvanized ,electro-galvanized and
spraying and soaking.
3. Steel grating is made by the world first-class equipment,which
can arrange the bearing bar and cross bar in longitude and latitude
order to certain distance.cross bar is pressed into the bearing bar
by high tension resistance weldingring which is controlled by
computer.so we can produce high quality gratings with firm
welding,smooth surface and high strength.
4. Sign of the shape of bearing bars.
F- Plain style
S- Serrated style
I- I-section style
5. Sign of surface treatment
G- Hot galvanizing (it is recommended)
P- Painted
U- untreated
Steel Grating Feature
1) The steel grating can reduce the supportive material,
investment, save workman and time.
2) It can be used in almost all applications.
3) Lightweight and economical.
4) Low maintenance cost, because the surface will be galvanized,
the anti-corrosion is 15~30 times than ungalvanized.
Application of Steel Floor Grating
1) It can be used in urben construction as drainage trench cover to
drain water and keep ground dry.
2) The serrated steel gratings will be used in the port, parking
lot, farmland and other places to be walk platform for pedestrian
and vehicles access and passing.
3) Forge-Welding gratings also will be used for industry platform,
power plant, water treatment industry, tower platform, etc.
4) Serrated steel gratings also be guardrail for garden, villa,
balcony, highway, etc.
item | value |
Warranty | 3 years |
After-sale Service | Online technical support |
Weight | Customzied |
Chemical Composition | steel ,iron |
Alloy Or Not | Is Alloy |
Secondary Or Not | Non-secondary |
Project Solution Capability | graphic design, 3D model design |
Application | Outdoor |
Design Style | Industrial |
Place of Origin | China |
Brand Name | Zhuote |
Model Number | Customzied |
Product name | Serrated Steel Grating |
Application | Warehouse,offfice building,school,park,farmhouse |
Surface treatment | Hot Dipped Galvanized |
Weld Structure | Steel Bar and Cross Ba |
Cross Bar Size | 6mm 8mm 10mm |
Weld Way | Pressure Welded |
Usage | Anti-Slip Places |
Standard | YB/T4001 |
Q:Why choose us?
A: Save Time, Save Cost, and Safety ! Each of our customers proved
this!
Q: How about the payment terms?
A:We usually use the T/T,L/C,D/P, Western Union. Trade assurance
service optional for over $100 order. (100% guaranteed
transaction by Alibaba ). L/C optional if over $50k. Paypal
optional if below $500.
Q: How about the delivery time?
A:Usually within 15- 20 days, customized order may need longer
time.
Q:Can you offer free sample?
A:Yes, but usually the customer need to pay the freight, We'll send
back the courier charge if you make an order.
Q: Can I have your products with my own logo on it?
A: Yes! Accept any custom logos, just send us your design in pdf.
ai, or high res jpg. We would send you layout art with your logo
on our products to check. The setup cost would be quoted per
artwork.
Q: Are you a manufacturer?
A:Yes, we have been in providing the professional products in wire
mesh field for 10 years.
